Pabilog ya 12 Pin Spring Pin Connector

Say Dongguan Xinteng Electronics Co., Ltd. et sakey ed saray sankamapanmatalkan ya manggagawa tan mansusuplay na circular 12 pin spring pin connector ed China, ya walaan na de-kalidad iran produkto tan maong a serbisyo. Manggayaga kayo ed pakyawan ya dakel ya matibay ya pabilog ya 12 pin spring pin connector ya walad stock dia manlapud pabrika mi. Wala met so customized service tan OEM&ODM service.

Sayan Circular 12 Pin Spring Pin Connector et sakey a melag, spring-loaded contact assembly ya ginawa parad saray programa na sensor na yurongan ed luluganan. Say labinduan pogo pin ed sakey a pabilog ya abung so manggagawa na self-aligning interface ed baetan na sensor pad tan vehicle harness. Say yurongan ed luluganan et atagey-ya yegyeg, atagey-siklo so kaliberliber. Saray spring-loaded contacts et mas maong nen saray fixed pins dia lapud say internal spring et mansiansian pressure anggano say interface et onliliber o onkapuy. Ipapaalagey mi iratan bilang custom parts. Ipawit yod sikami so mechanical drawing yo tan putoten mi ray kagawaan unong ed geometry yo.

No manaanap kay 12 pin pogo pin connector parad heated seat controller, odino pressure-mapping array, sayan pabilog ya format et mamasiansia ed footprint ya melag legan ya mangiiter na labinduan nanduruman signal paths. Bilang sakey a manggagawa na pogo pin connector ya walay in-house turning, stamping, tan molding, kontrolado mi so contact geometry, kapal na plating, tan saray tolerances na abung manlapud raw material anggad pinal ya test.

Saya so sakey a custom-designed 12-pin spring-loaded connector. Say inkalapagan a diametro to et kulang na 16.5mm, tan say katagey to et 15.38mm. Mankikimey iya ed loob na temperaturan -25℃anggad +60 degree, ya walay sankatageyan ya kuryente ya 1A tan say karukey na bilay to et anggad 10,000 a siklo.

• Self-Compensating Contact Force

Kada posisyon et sakey a precision-machined spring pogo pin connector element. Say internal spring et mangiiter na normal a puersa ed tapew na mating surface-kaslakan ya 60-120 grams kada contact depende ed pankaukolan na circuit mo. Sayan puersa et ag-onkupas kayari na panag-usar odino panag-yegyeg. Diad saray desinyo na fixed-pin, say puersa na kontak et onkupas legan ya onrelaks so socket odino onlelereg so blade. Dia, say primabera et ontulak. Say resulta et malet ya resistensya ed pidedeneng ed loob na 10,000 a siklo na panag-asawa.


• Automotive-Grade Durability

Say kaliberliber ed loob na yurongan na luluganan et grabe. Idetalye mi ray materyales unong ed saya:
Contact plating: Balitok ed tapew na nikel ed saray signal pin parad malet ya abeban resistensya. Say pinilin panag-plating ed saray power pin pian naasikaso so gastos ya ag nasasakripisyo so proteksion ed corrosion.
Panayaman:Atagey a temperatura na HTN, ya aka-rate na -40℃anggad +125℃tan UL94 V-0.
Subol:Stainless steel odino music wire, ya ag-inmabobon pian ag-onlereg so danum tan asin.
Say asemblea et na-validate parad temperature cycling, mechanical shock unong ed IEC 60512, tan saray profile na humidity ed loob na luluganan. No say programa yo et mankaukolan na AEC-Q200-style ya kwalipikasyon, suportaan mi itan ya test flow tan iter mi so data package.

• Compact 12-Position Circular Layout

Say pabilog a porma et walaan na labinduan kontak ed sakey a masimpit a diametro. Importante itan no say konektor et nepeg ya onloob ed loob na riles na yurongan, diad silong na tapi, odino diad loob na slim sensor control module. Say 360-degree symmetry et mamapasimpli ed panagtipon: anggapoy keyed orientation fight parad saray line operators. Sarag tayon idagdag so molded polarization ribs no say harness side yo et mankaukolan na foolproof mating.

• Andukey a Siklo na Bilay

Say de-kalidad ya spring loaded pin connector na sayan klase et na-rate parad 10,000 anggad 50,000 a siklo ed saray static test fixtures tan 5,000+ ed saray moderate-vibration seating applications. Parad sakey a sensor na yurongan ya makakanengneng na sagpaminsan ya pakadiskonekta na harness legan na serbisyo, satan a margin et mankabaliksan na field-proven reliability.

Sakey kamin manggagawa na pogo pin connector ya mankikimey manlapud saray drowing na kustomer tan saray detalye na uusaren da. Anggapoy limitasyon ed katalogo. Ipapasen mi so kagawaan ed geometry mo, aliwan diad geometry mi.

• Electrical Configuration

Bilang na pin tan asainmin:1pins anggad 200 pins, odino sakey a panlalaok na signal tan abeban-current power pins.
Kaplesan ya kapasidad: Indibidual ya pin ya in-rate manlapud0.5A anggad 60Adepende ed diametro tan say plating spec.
Impedance control: Parad analog o low-voltage ya digital sensor ya signal, ipapara mi so contact resistance tan capacitance ed saray pankaukolan na circuit yo.

• Mechanical Geometry

Diametro tan katagey na abung: Say kagawaan et putoten ed limitasyon na sukat mo.
Estilo na pangikabit:SMT, DIP, Right Angle, Soldering, Double Ended, Threadedparad PCB sensor boards, panamegley na-hole, odino floating panel-mount parad harness-side assemblies.
Polarization tan keying: Idagdag so molded ribs odino staggered pin lengths parad panag-sequence. Ipaliis so mis-mating ed linya na produksyon.

• Saray Pansumpal ed Tapew

Gold flash, 3μ", 5μ", 10μ", odino 15μ" ya balitok ed 50μ" ya sankaabebaan ya nickel.
Matte tin ed solder tails no mas labay moy mas abeban-gastos ya termination.
Saray custom plating splits parad mixed-signal tan power applications.

• Inkasakey ya Kable tan Overmolding

No labay moy asumpal ya harness imbes ya anggapoy connector, mangiter kami na:
Pan-strip, pan-crimp, tan pan-solder na alambre.
Overmolded strain relief ya walay IP-rated sealing no say konektor et ompaway ed seat frame ya onloob ed sakey a wet zone.
Saray tampok na panag-label tan panagseguro na posisyon na konektor (CPA).

Manunan aplikasyon: Sistema na sensor na yurongan na luluganan, ya espisyal ya adesinyo na Circular 12 Pin Spring Pin Connector parad sistema na sensor na yurongan na luluganan.

Kaiba ed saray kaslakan ya aplikasyon:

1. Occupant detection sensors: Ipapaarap so capacitive odino pressure-based presence data ed SRS control module.
2. Seat heating tan ventilation controllers: Mangiyakar na PWM odino abeban-koryenti ya kuryente ed saray heating elements tan blower motors.
3. Posisyon na yurongan tan pressure mapping: Multi-zone sensor arrays ya kaukolan so malinis, abeban-noise signal path.

Say spring-loaded ya paraan et epektibo dia ta say mating interface et mabetbet ya flex circuit odino PCB pad ed loob na cushion. Saray pogo pin et malet ya makapitongtong ed saray pad odino saray plated zone ya agla kaukolan so tradisyonal ya mating connector half. Saya so mamawala na bilang na parte tan katagey na stack.

Arum nin Uusaren ed Luluganan tan Industriya

1. Saray module na kontrol na manibela
2. Dashboard switch clusters
3. Saray test fixtures tan ICT probes
4. Saray interface na pantalan na panagkarga ed saray kagawaan ed industriya

Manpapaandar kami na sistema na kalidad ya espisipikon adesinyo parad panaggawa na luluganan:
Ontumbok ed IATF 16949: Saray produkto mi et sigpot ya ontutumbok ed sistema na panangasikaso na kalidad parad saray supplier na luluganan.
ISO 9001: Framework parad Basic Quality Management System.
Ontumbok ed RoHS tan REACH: Amin ya pogo pin tan pogo pin connectors et ontutumbok ed saray totontonen ed materyal.

Sakey a Tier-1 seat supplier ed North America so mankaukolan na 12 pin pogo pin connector pian na-interface so balon capacitive occupant sensor ed flex circuit. Say wala lan fixed-pin header et ag akasumpal ed vibration test ed 5G random lapud say socket et nanrelaks kayari na temperature cycling. Nanggawa kami na pabilog ya spring-loaded assembly ya walay staggered pin lengths parad sequencing tan 5μ" gold ed signal pins. Say assembly et akapasa na 10G random vibration tan 1,000-oras ya temperature cycling. Say PPAP Level 3 et inaprobaan ed loob na 14 a simba. Say connector et wala la natan ed produksyon ed 5000 units kada taon.

Saray inhinyero et mabetbet ya mantetepet no kasin nakaukolan so spring pogo pin connector no mas abeba so bili na standard pin header. Say ebat et mandedepende ed no antoy nadiwit na konektor tan no panon kabetbet so igalaw to.

Diad saray seat sensor modules, say mating surface et mabetbet ya flex circuit odino melag ya PCB pad ed loob na cushion. Say fixed pin header et kaukolan toy mating socket odino sakey a soldered companion connector. Saya so mangarum na bilang na parte, katagey na stack, tan oras na panagtipon. Say spring-loaded contact et direktan onpeket ed PCB pad odino flex gold area. Ekalen mo so komaduan kapaldua na konektor, putoten so katagey na stack, tan ekalen so posiblin failure mode.

Say mas importante, saray yurongan na luluganan et onkukurong. Say fixed contact pair et nayarin naandi so continuity to no say cushion et man-compress odino say frame et twist. Say spring ed sakey a Circular 12 Pin Spring Pin Connector et manbiabiahe pian nasepsep itan ya galaw. No say sensor yo et manbabasa na millivolt-level capacitive odino pressure signals, aliwan opsyonal itan ya pantultuloy. Saya so pandumaan na onlabas ya SRS calibration tan say warranty claim.
